Ever been annoyed by someone else’s music in a shared space? Or struggled to have a private conversation in a busy office? Researchers at Penn State University might have just solved these everyday acoustic headaches with a breakthrough that creates “sound bubbles” only the intended listener can hear.
These localized audio spots, which the researchers dubbed “audible enclaves,” can be placed with pinpoint accuracy—even behind obstacles like human heads—while remaining silent to everyone else in the room.
“We essentially created a virtual headset,” said Jia-Xin “Jay” Zhong, a postdoctoral scholar in acoustics at Penn State. “Someone within an audible enclave can hear something meant only for them — enabling sound and quiet zones.”
How Audible Enclaves Work
Published in the Proceedings of the National Academy of Sciences, the research tackles a challenge in acoustics that has long frustrated audio engineers. Sound waves naturally spread out as they travel, making it nearly impossible to contain them without physical barriers. This is why conversations carry across rooms and why traditional speakers fill entire spaces with sound.
“We use two ultrasound transducers paired with an acoustic metasurface, which emit self-bending beams that intersect at a certain point,” said corresponding author Yun Jing, professor of acoustics in the Penn State College of Engineering. “The person standing at that point can hear sound, while anyone standing nearby would not. This creates a privacy barrier between people for private listening.”
The system works by sending out two beams of ultrasonic sound—frequencies too high for humans to hear—that travel along curved paths and meet at a specific target location. Using 3D-printed structures called metasurfaces, they shape these ultrasonic beams to bend around obstacles like a person’s head.
By positioning the metasurfaces in front of the two transducers, the ultrasonic waves travel at two slightly different frequencies along a crescent-shaped trajectory until they intersect. The metasurfaces were 3D printed by co-author Xiaoxing Xia, staff scientist at the Lawrence Livermore Laboratory.
Neither beam is audible on its own—it is the intersection of the beams together that creates a local nonlinear interaction, which generates audible sound. The beams can bypass obstacles, such as human heads, to reach a designated point of intersection.
Breaking Sound Barriers
Most audio technologies work within narrow frequency ranges, but this system demonstrated effectiveness across an impressive spectrum from 125 Hz to 4 kHz. This range covers most frequencies needed for speech and music reproduction, making it practical for real-world applications.
The approach differs fundamentally from existing directional sound technologies. Previous attempts to create focused audio have required massive speaker arrays and complex processing, especially for lower frequencies with longer wavelengths. Commercial “sound beam” products exist but can’t bend around obstacles or create such sharply defined listening spots.
Perhaps most impressive is the system’s compact size. The researchers achieved their results using a source aperture measuring just 0.16 meters—tiny compared to conventional approaches that would require much larger equipment to direct low-frequency sounds.
To verify the technology works with actual content rather than just test tones, the team conducted rigorous testing. “We used a simulated head and torso dummy with microphones inside its ears to mimic what a human being hears at points along the ultrasonic beam trajectory, as well as a third microphone to scan the area of intersection,” said Zhong. “We confirmed that sound was not audible except at the point of intersection, which creates what we call an enclave.”
The researchers tested the system in a common room with normal reverberations, meaning it could work in various environments like classrooms, vehicles, or even outdoors.
Where Will We See Audible Enclaves?
This technology opens up fascinating possibilities. Museums could deliver exhibit narration to visitors in specific spots without creating audio overlap. Office workers could receive private notifications without disrupting colleagues. Cars could create individual sound zones for each passenger, letting the driver hear navigation instructions while rear passengers enjoy different music.
The applications extend beyond convenience. The same approach could create targeted quiet zones by delivering precisely placed noise-cancellation signals. Hospitals could maintain quiet areas while allowing necessary communication in adjacent spaces—something traditional noise control systems struggle to accomplish.
For now, researchers can remotely transfer sound about a meter away from the intended target, and the sound volume is about 60 decibels, equivalent to speaking volume. However, the researchers said that distance and volume may be able to be increased if they increased the ultrasound intensity.
The current system requires high-intensity ultrasound to produce moderate audio levels due to conversion inefficiency. While the levels used fall within safety guidelines, this aspect needs further refinement.
Audio quality presents another hurdle. The interaction introduces some distortion, which could affect complex audio content. However, the team believes signal processing techniques could compensate for these effects in future versions.
Audible enclaves certainly offer a compelling and exciting solution to a long-standing problem, creating bubbles of sound that exist only where wanted and nowhere else. By focusing sound with laser-like precision, this technology could transform our relationship with audio in shared spaces, making private listening truly private without isolating listeners from their surroundings.
